1.Coattech 7-HP Heat Pump Dryer | Industrial Moringa Dehydration
2.Maximize moringa quality with the Coattech 7-HP Heat Pump Dryer.
Features low-temp dehydration,
180-tray capacity, and uniform airflow. Request a quote today!
The Coattech 7-HP Heat Pump Dryer (Model G2-07-HP) is a premium
industrial-scale dehydration system specifically optimized for
processing high-quality moringa. Constructed with a fully enclosed
closed-loop system and high-density insulated paneling, the dryer
delivers extreme thermal efficiency for continuous operations. By
utilizing controlled, low-temperature dehydration operating between
15°C and 80°C, this system ensures maximum nutrient retention and
color fidelity. It is the ultimate heavy-duty solution for
agricultural processors seeking reliable, high-volume production
without compromising the delicate biochemistry of their product.
3.Key Advantages
1.Nutrient & Color Preservation: Low-temperature dehydration
prevents the breakdown of heat-sensitive vitamins, while controlled
moisture extraction prevents browning to ensure a vibrant,
export-grade green powder.
2.Engineered for Uniform Dehydration: Features a high-volume
circulation system powered by a bank of 6 heavy-duty fans
generating 3000-4500 m³/H of continuous airflow. Aerodynamic floor
channels force dry air evenly across all 180 trays simultaneously,
preventing localized mold or under-drying.
3.Heavy-Duty Ergonomic Access: Built with an integrated loading
ramp specifically designed to accommodate heavy trolley access into
the dual-chamber trolley system.
4.Scalable Automation Options: Choose the Standard Architecture
with a 7-inch touchscreen controller, or upgrade to Premium PLC
Integration (Siemens or Schneider) for unparalleled logic control
and maximum reliability in continuous facility operations.
5.Accelerated Deployment: Benefit from a rapid 15 to 20-day
production lead time, with direct shipping and heavy freight
logistics (managing 1.2 to 1.5 tons) deployed directly to
facilities in locations like Botswana.
| Parameters / Specifications | Coattech (Our Proposal) | Competitor A | Competitor B | Coattech Core Advantages |
| Core Heating Technology | Air Source Heat Pump | Pure Electric Heating | Pure Electric Heating | Fundamental difference! Heat pumps transfer free heat from the air; electric heaters
directly burn power. |
| Energy Efficiency Logic | 1 kW Electricity = 3~4 kW Heat | 1 kW Electricity = 1 kW Heat | 1 kW Electricity = 1 kW Heat | Absolute game-changer! To produce the same heat, Coattech uses only 1/3 of the
electricity. |
| Max Input Power | Only 15.8 kW | 38.285 kW | Unknown (Estimated >40 kW) | Saves money every single day. Power consumption is less than half of competitors. |
| Est. Daily Power Consumption (10 Hours) | ~158 kWh | ~383 kWh | Estimated >400 kWh | Saves over 225 kWh daily! Recovers the machine price difference in just months through
electricity savings. |
| Tray Quantity | 180 pcs | 120 pcs | Unknown (Opaque quote) | 50% more trays! Allows for thin-layer spreading, crucial for perfect drying. |
| Tray Dimensions | 800 X 600 mm | 600 X 800 mm | Unknown | Standardized industrial size. |
| Total Drying Area | 86.4 m² | 57.6 m² | Unknown | Larger area ensures thorough hot air circulation and exponentially higher
drying efficiency. |
| Machine Dimensions (LXWXH) | 5200 X 2220 X 2250 mm | 3800 X 2100 X 2100 mm | 5300 X 1800 X 2200 mm | Coattech's machine is much larger and robust, guaranteeing better insulation thickness. |
| Standard Capacity per Batch (KG) | 600 - 750 KG (Scientific & Effective) | 600 - 850 KG (Exaggerated) | 1000 KG (Exaggerated) | Competitors claim high capacity with small tray areas, causing
thick material stacking and wet/ruined interiors,Our engineer Promise if you put the moringa thicker,it could up to
1000KG,no problem |
| Drying Quality & Physics | Thin layers, even air penetration | Thick layers, blocked air flow | Thick layers, blocked air flow | Coattech yields unburned, perfectly dried products. Excellent appearance = Higher selling price. |
| Safety & Weather Resistance | Closed-loop (Weather-proof). No heating tubes (Zero fire risk). | Red-hot electric tubes (High fire risk). | Red-hot electric tubes (High fire risk). | Heat pumps use warm air, not dangerous red-hot elements. 100% safe
& stable even in heavy rain. |
Ready to scale your facility's processing power and lock in your
15-20 day manufacturing window?
Secure your production timeline today and contact our engineering
team to discuss your custom site requirements!
