    Customizable Floor Rail Coating Line Room Structures For Superior Finishes

    Ask Lasest Price
    Brand Name : CoatTech
    Model Number : Floor-R9
    Certification : CE
    Price : USD150/SET-USD500/SET
    Payment Terms : T/T
    Supply Ability : 100SET/MONTH
    Delivery Time : 15 DAYS After Deposit
    • Product Details
    • Company Profile

    Customizable Floor Rail Coating Line Room Structures For Superior Finishes

    Customizable Room Structures for Superior Finishes with Floor Rail Coating Line


    The Floor Rail Coating Line provides advanced solutions for the surface treatment of heavy workpieces.

    Utilizing an unpowered translation vehicle and ground conveyor chain, the system ensures smooth transitions

    through sanding, cleaning, drying, spray painting, and baking stages. Customizable room structures, including

    polishing, cleaning, drying, spray painting, and baking rooms, cater to specific product requirements, delivering

    superior finishes and enhancing productivity.

    Machine TypeRoller Coating line
    Warranty of core components1 Year
    Core ComponentsMotor
    Place of OriginGuangdong, China
    Warranty1 Year
    Key Selling PointsAutomatic
    Applicable IndustriesAutomobile Wheels, Turntables, Ovens Machinery Repair Shops, Manufacturing Plant, Construction works
    Weight (KG)200
    SubstrateSteel
    ConditionNew
    CoatingPainting
    Brand NameCoatTech
    Voltage380V
    Power5KW
    Dimension (L*W*H)AS YOUR NEEDS
    FunctionSpraying Coating
    ColorCustomizable
    Weight24kg
    Voltage380v
    Power75kw
    Size24330*6300*3700mm
    Product nameRoller Coating line-1
    KeywordsPainting Line
    Packaging and Delivery
    Selling UnitsSingle item
    Single package size60X50X40 cm
    Single gross weight50.000 kg
    Lead time
    Quantity (sets)>1
    Lead time (days)15

    Used for surface treatment of large, heavy workpieces with low productivity requirements;

    Process flow:pieces on-->sanding-->cleaning-->drying-->spray painting-->baking paint-->pieces off;

    The room structure includes: polishing room, cleaning room, drying room, spray painting room, and baking room

    (customized according to the product);

    Translation car: It is welded and formed by I-beam and channel steel, and the surface is paved with 8mm thick steel plate;

    Ground conveyor chain equipment description:

    It is mainly composed of driving device, traction chain, tensioning device and conveyor track.

    ⑴Driving device

    The power of the driving device is transmitted to the driving spindle through the motor-reducer and the transmission chain.

    Finally, the driving sprocket drives the conveyor chain, making the conveyor chain move forward along the conveyor chain track;

    the use of a cycloidal pinwheel reducer can greatly improve the transmission efficiency. , and the movement is reliable.

    ⑵ Traction chain

    The chain consists of pin shaft, chain plate, pusher chain plate and roller sleeve. The pusher spacing can be assembled into

    various shapes according to needs.just to meet the needs of work rhythm.

    This series of conveyor chains all use high-quality manganese steel as chain plates, and all require specified tensile tests

    before leaving the factory.

    ⑶Tensioning device

    This device ensures that the entire conveyor chain always maintains a relatively stable tension during operation.

    At the same time, it can absorb or compensate for the installation error of the conveyor chain, the expansion and contraction caused

    by thermal expansion, contraction and force deformation during operation. Ensure that the conveyor chain has an initial tension at the

    winding-out point of the drive device and eliminate devices that generate negative tension in the entire line.This series of tensioning devices mainly uses screw rods for tensioning. Its structure is relatively simple and compact, and its tensioning force is relatively stable;

    ⑷Conveyor track

    The trolley track adopts 30kg/m light rail (the foundation is pre-embedded in construction), the running wheels use light rail steel wheels,

    and the trolley brackets are all welded from section steel, with a solid structure;The entire line adopts PLC control, stepless speed adjustment, and is equipped with multiple induction probes and control buttons.




    Peace Environmental Protection always adheres to the core principle of "quality first, honest service" and provides
    excellent solutions for customers in the field of environmental protection equipment. The factory is located in
    Guangzhou City, Guangdong Province.
    The company's main products include environmental protection equipment such as spray booth,coating line,painting line
    and waste gas and wastewater treatment,if you have any inquiry,please leave the inquiry here directly,will be respond to you within 12 hours
    We will make the exact Design Drawing,Design Case in words,and Quotation in detail,just waiting for you leave the message here.
